Hi all,

I am a newbie. So, sorry if it is too simple or already solved in
another thread. Does anyone have an idea how to create a crack surface
within a volume like the one in the attached image, which also has
double nodes on both sides of the crack? The crack surface does not go
all the way through the volume. If that is not possible, what should the
best way to create the closest mesh structure in gmsh?

Best,

Bahadir
